Increased Flexibility in Mounting Options, Reducing Depth and Weight by 50%

Weight Comparison (20" Double-Row Type)

Depth Difference (Double-Row Type)


Depth Comparison (Single-Row Type)



Provides Improved Road Visibility, Far Brighter than Stock Headlamps

The most popular 20inch double-row light bar (622SD) offers sufficient light output 154,000cd (candela).
Largest size in the range, 50inch double-row light bar (652SD) provides the most powerful light output 276,000cd.
Reference: At the time of vehicle inspection in Japan, lower limit of high beam light intensity is 12,000cd.
Halogen
Halogen
Halogen

Offering Powerful Driving x Spot (Hybrid) Beam Pattern

Delivers powerful yet well-designed hybrid beam pattern.
Employing two kinds of reflectors to create a farther reaching spot beam and wide driving beam pattern.

Available in Single and Double-Row Type

Double-Row Type
Enhanced light output for heavy-duty specification, offering outstanding utility and presence.
Single-Row Type
Designed to fit in the bumper or to be embedded, lightweight and slim design contributes to drivers especially when used in motorsports.

Available in Various Sizes for Intended Use

Halogen
IMAGE: 50" DOUBLE ROW (652SD)
Halogen
IMAGE: 40" DOUBLE ROW (642SD)
Halogen
IMAGE: 30" SINGLE ROW (631SS)
Halogen
IMAGE: 20" DOUBLE ROW (622SD)

Halogen
IMAGE: 20" SINGLE ROW (621SS)
Halogen
IMAGE: 10" DOUBLE ROW (612SD)
Halogen
IMAGE: 10" SINGLE ROW (611SS)

Extreme Grill Guard

Halogen
IPF logo on "Extreme Grill Guard" is detachable, and it provides a distinctive look on the lights. Well-crafted IPF logo makes a unique style of light cover.

One-Year Warranty


Super Tough Body

Extreme Grill Guard
Provides improved crashproof and its tough body with up to 10G vibration resistance.

Water/Dustproof Design (IP68)


Prevents Water Ingress in Harsh Environments

Water/Dust Resistant Connectors


Using reliable waterproof connectors of Deutsch (10"/20"/30") or AMPHENOL (40"/50"), so as to prevent water ingress through connectors.

Complete Wiring Harness Kit


Complete wiring harness kit includes 12V relay and splash-proof switch (with indicator light).
*Optional 24V relay (WA-18) is available for 24-volt vehicles or trucks.

Operating Temperature Range -30°C∼+70°C(-22°F∼+158°F)

Halogen
Halogen

MOUNT IMAGE

Halogen
(642JM2 / 622SD)
Halogen
(642JM2 / 622SD)
Halogen
(642JM2)
Halogen
(642JM2)

Halogen
(631SS)
Halogen
(631SS)
Halogen
(622SD)
Halogen
(622SD)
Halogen
(642SD)
Halogen
(642SD)

PRODUCT IMAGE

IMAGE: 50" DOUBLE ROW (652SD)
Halogen
Halogen
Halogen
IMAGE: 40" DOUBLE ROW (642SD)
Halogen
Halogen
Halogen
IMAGE: 30" SINGLE ROW (631SS)
Halogen
Halogen
Halogen
IMAGE: 20" DOUBLE ROW (622SD)
Halogen
Halogen
Halogen
IMAGE: 20" SINGLE ROW (621SS)
Halogen
Halogen
Halogen
IMAGE: 10" DOUBLE ROW (612SD)
Halogen
Halogen
Halogen
IMAGE: 10" SINGLE ROW (611SS)
Halogen
Halogen
Halogen

Product Dimensions & Instruction Manual

Halogen
Halogen

Instruction Manual: 600 S-Series

Halogen

LINE UP

Part Number Lumen Candela Power Consumption  Color Temperature  Weight Price
611SS 3400lm 68,000cd 40w 6000k 700g OPEN
612SD 4600lm 90,000cd 49w 6000k 1000g OPEN
621SS 6900lm 86,000cd 87w 6000k 1,100g OPEN
622SD 9500lm 154,000cd 100w 6000k 1,650g OPEN
631SS 10000lm 104,000cd 132w 6000k 1,600g OPEN
642SD 20000lm 273,000cd 210w 6000k 2,900g OPEN
652SD 26500lm 276,000cd 278w 6000k 3,500g OPEN
///Term description///
Lumen It is the unit of the optical energy generated from an electric bulb.
When numerical value is large, the brightness of the bulb become brighter.
Candela Measure the brightest point numerically when a head lamp is equipment.
kelvin Kelvin temperature is a numerical measurement that describes the color appearance of the light produced by the lamp and the color appearance of the lamp itself,
expressed on the Kelvin (K) scale.

Light source

Halogen Halogen light bulbs are a special type of incandescent light bulb.
They are filled with halogen gas, have a tungsten filament, and are enclosed in quartz glass.
It is intend to be out of date, but still bright and gentle light in the eyes.
H.I.D High Intensity Discharge, it the new replacement technology for halogen headlights.
Brightness is the biggest advantage of an HID conversion. Not only will you be able to see farther and better at night, but other drivers will be able to see as well.
Its estimated that an HID conversion kit will increase your brightness from a halogen set up as much as 300%.
LED LED lighting is a lamp or other light that uses light-emitting diodes (LEDs) as a source of illumination.
LEDs are more expensive than traditional bulbs. They are heat sensitive, so if they are not used with a steady and consistent current, they can stop working or fade quicker.
These lights are also usually best used in directional lighting rather than room lighting, although some changes in design may improve this.
